What is the approximate resolution of a flowmeter that converts a 12-bit register value representing flow rate to a 4-20 mA analog output?
- 0.006 percent of span
- 0.025 percent of span
- 0.10 percent of span
- 0.40 percent of span
The analog signal represents the flowmeter span in 4,096 steps (2 to the 12th power). The resolution is one step, where each step represents 1/4,096 of the span, which is 0.024 percent of span. Answer B is the best answer.
Additional complicating factors
Resolution is not the same as accuracy. This digital-to-analog converter has 4,096 steps, but its accuracy might be +/- 4 steps, which is 4 times its resolution, or 0.10 percent of span.
Accuracy specifications for flowmeter analog outputs are commonly expressed as a percentage of flow rate plus the digital-to-analog converter accuracy expressed as a percentage of span, such as 0.75% rate plus 0.10% span. The accuracy of this flowmeter at 20 percent flow is 1.25 percent of the flow rate (0.75 + 0.10/0.20), which is almost 70 percent higher than the measurement accuracy of the flowmeter itself. Operating at lower flow rates will further degrade accuracy.
